Watlow Series SD • 59 • Chapter 11 Factory
11
Chapter 11: Factory Page
To go to the Factory Page, press both the Up
¿
and Down
¯
keys for six seconds from the Home Page.
{FAct}
will
appear in the upper display and
{page}
in the lower display.
• Press the Advance Key ‰ to move through the parameter prompts.
• Press the Up ¿ or Down ¯ keys to change the parameter value.
• Press the Infinity Key ˆ at any time to return to the Home Page.
Display Parameter Name
Description
Settings Range
(Integer values for Modbus
in parentheses.)
Default Modbus*
(less 40,001
offset)
Read/Write
Appears if:
[AMb]
[AMb]
Ambient Temperature
Displays the current calculated
ambient temperature.
-50.0 to 300.0°F NA Always active.
[A;mn]
[A.Mn]
Minimum Recorded Ambient
Temperature
Displays the minimum recorded
ambient temperature.
-50.0 to 300.0°F NA NA Always active.
[AMa]
[A.MA]
Maximum Recorded Ambient
Temperature
Displays the maximum recorded
ambient temperature.
-50.0 to 300.0°F NA NA Always active.
[dSPL]
[dSPL]
Display Intensity
Increase or decrease the bright-
ness of the upper and lower
display.
15 to 100% duty 100 NA Always active.
[rESt]
[rESt]
Restore Factory Calibration
Replaces the user calibration pa-
rameters with the factory calibra-
tion parameters.
[~~no] (0)
[~yES] (1)
[~~no] (0)
208 R/W Always active.
[USr;r]
[Usr.r]
Restore User Settings
Restores customer configured set-
tings. Two sets of user settings
for non-profiling version and one
set of user settings for profiling
version.
[~~no] (0)
[Set1] (1)
[Set2] (2)
[~~no] (0)
[~yES] (1)
[~~no] (0)
209 R/W Non-profiling version
only.
(SD_ C - _ _ _ _ - _ _
_ _ )
Profiling version only.
(SD_ R - _ _ _ _ - _ _
_ _ )
[USr;S]
[USr.S]
Save User Settings
Saves customer configured set-
tings. Two sets of user settings
for non-profiling version and one
set of user settings for profiling
version.
[~~no] (0)
[Set1] (1)
[Set2] (2)
[~~no] (0)
[~yES] (1)
[~~no] (0)
210 R/W Non-profiling version
only.
(SD_ C - _ _ _ _ - _ _
_ _ )
Profiling version only.
(SD_ R - _ _ _ _ - _ _
_ _ )
[PrF;
r]
[PrF.r]
Restore User Profiles
Restores the current customer
configured profiles
[~~no] (0)
[~yES] (1)
[~~no] (0)
209 R/W Profiling version only.
(SD_ R - _ _ _ _ - _ _
_ _ )
[PrF;S]
[Prf.S]
Save User Profiles
Saves the current customer con-
figured profiles.
[~~no] (0)
[~yES] (1)
[~~no] (0)
210 R/W Profiling version only.
(SD_ R - _ _ _ _ - _ _
_ _ ).
[dFLt]
[dFLt]
Default Parameters
Reset all parameters to the de-
fault values (may take up to 4
seconds to complete).
[~~no] (0)
[~yES] (1)
[~~no] (0)
207 R/W Always active.
