Watlow Series SD • 43 • Chapter 8 Programming
Chapter 8: Programming Page
8
The Programming Page allows you to select what parameters appear on the Operations Page. To go to the Pro-
gramming Page, press both the Advance
‰
and Infinity ˆ keys for six seconds from the Home Page. [Prog] will
appear in the upper display and [PAgE] will appear in the lower display.
• Press the Advance Key ‰ to move through the parameter prompts.
• Press the Up ¿ or Down ¯ key to change the parameter value.
• Press the Infinity Key ˆ at any time to return to the Home Page display.
Note: This chapter only applies to the static set point and profiling versions of the Series SD (SD_C or R - _ _ _ _ - _ _ _ _).
Display Parameter name
Description
Settings Range
(Integer values for Modbus
in parentheses.)
Default Modbus*
(less 40,001
offset)
Read/Write
Appears if"
[``P1]
Parameter Location 1
[none]
(0) None
[`CAL] (1) Calibration Offset
[`C-F] (2) Temperature Units (Setup
Page)
[A1;Lo] (3) Alarm 1 Low
[A1;hi;] (4) Alarm 1 High
[A2;Lo] (5) Alarm 2 Low
[A2;hi] (6) Alarm 2 High
[A3;Lo] (7) Alarm 3 Low
[A3;hi] (8) Alarm 3 High
[hys1] (9) Alarm Hysteresis 1 (Setup
Page)
[hys2] (10) Alarm Hysteresis 2 (Setup
Page)
[hyS3] (11) Alarm Hysteresis 3 (Setup
Page)
[addr] (12) Modbus Device Address
(Setup Page)
[`Aut] (13) Autotune
[A-m] (14) Auto-Manual
[Po;ht] (15) Power Heat
[Po;CL] (16) Power Cool
[ht;M] (17) Heat Control Method
[Pb;ht] (18) Prop. Band Heat
[It;ht] (19) Integral Heat or
[re;ht] (19) Reset Heat
[dEht] (20) Derivative Heat or
[ra;ht] (20) Rate Heat
[db;ht] (21) Dead Band Heat
[h;hys] (22) Heat Hysteresis
[CL;M] (23) Cool Control Method
[Pb;Cl] (24) Prop. Band Cool
[It;Cl] (25) Integral Cool or
[rE;Cl] (25) Reset Cool
[dE;Cl] (26) Derivative Cool or
[ra;Cl] (26) Rate Cool
[db;Cl] (27) Dead Band Cool
[C;hys] (28) Cool Hysteresis
[prop] (29) Proportional Term
[``It] (30) Integral Term
[``dE] (31) Derivative Term
[rP;rt] (32) Ramp Rate (Setup Page)**
[Po;ht] (15)
48 R/W All parameter loca-
tions always appear
on the Programming
Page.
Static set point ver-
sion
(SD_C - _ _ _ _ - _ _
_ _ ) P1 to P20
Profiling version
only.
(SD_R - _ _ _ _ - _ _
_ _ ) P1 to P23
[~~P2]
Parameter Location 2
[`gsd] (35)
49 R/W
[~~P3]
Parameter Location 3
[`Aut] (13)
50 R/W
[~~P4]
Parameter Location 4
[`CAL] (1)
51 R/W
[~~P5]
Parameter Location 5
[ht;m] (17)
52 R/W
[~~P6]
Parameter Location 6
[pb;ht] (18)
53 R/W
[~~P7]
Parameter Location 7
[re;ht] (19)
54 R/W
[``P8]
Parameter Location 8
[ra;ht] (20)
55 R/W
[``P9]
Parameter Location 9
[h;hys] (22)
56 R/W
[`P10]
Parameter Location 10
[CL;m] (23)
57 R/W
[`P11]
Parameter Location 11
[pb;Cl] (24)
58 R/W
[`P12]
Parameter Location 12
[re;CL] (25)
59 R/W
[`P13]
Parameter Location 13
[ra;Cl] (26)
60 R/W
[`P14]
Parameter Location 14
[C;hys] (28)
61 R/W
[`P15]
Parameter Location 15
[A1;hi] (4)
62 R/W
[`P16]
Parameter Location 16
[A1
;Lo] (3)
63 R/W
[`P17]
Parameter Location 17
[A2;hi] (6)
64 R/W
[`P18]
Parameter Location 18
[A2;Lo] (5)
65 R/W
[`P19]
Parameter Location 19
[A3;hi] (8)
66 R/W
[`P20]
Parameter Location 20
[A3Lo] (7)
67 R/W
[`P21]
Parameter Location
21***
[Ent1] (32)
68 R/W
[`P22]
Parameter Location
22***
[Ent2] (33)
69 R/W
[`P23]
Parameter Location
23***
[Ent3] (34)
47 R/W
Note: All parameter locations have the same range of possible values.
**Static set point version (SD_ C - _ _ _ _ - _ _ _ _ )
***Profiling version only. (SD_ R - _ _ _ _ - _ _ _ _ )
