Section 3 Auto-Zone Plus
3-32 Programming
CV Read/Reset
Operations
If the Unit ID you entered was for a Constant Volume AHU, the following menus will
appear. Any references in this section to CVAHU are referring to the Constant Volume
Air Handling Unit.
CVAHU Menu #1
CVAHU Menu #2
1) CVAHU Status
2) CVAHU Setpoints
MENU) Next Menu
ESC) To Exit
1) CVAHU Status
View the current temperatures
and operating modes for this
Constant Volume AHU.
2) CVAHU Setpoints
View or change any of the
available setpoints for this
Constant Volume AHU.
MENU) Next Menu
Access the next Menu Page for
the Constant Volume AHU.
1) Schedules
2) Force Modes
MENU) Previous Menu
1) Schedules
View or change any of the Week
Schedules or Holidays for this
Constant Volume AHU.
2) Force Modes
Select this menu to override the
currently scheduled operating
mode.
MENU) Previous
Menu
Return to the previous menu
shown above.
