Auto-Zone Plus Section 3
Programming 3-33
Constant Volume AHU
Status
Line 1 Displays the currently selected CVAHU and its current operating software version
on all Status Screens shown below.
Status Screen #1
Status Screen #2
CVAHU # 18 vl.xx
Occupied Mode
Neutral Mode
Line 2 -
Unoccupied Mode
Occupied Mode
Holiday Active
Push Button Override
Forced Occupied
Forced Unoccupied
Forced Fan Only Mode
Line 3 -
Neutral Mode
Cooling Mode
Heating Mode
Line 4 -
(Reserved for Future Use)
This Line is Blank
CVAHU # 18 vl.xx
Temperature: 78.6°F
CSP 75.0° HSP 72.0°
Slide Adjust.: 0.0°
Line 2 -
Displays the current Zone Temperature.
Line 3 -
Displays the currently active Cooling
Setpoint (CSP) and Heating Setpoint (HSP)
Line 4 -
Displays the current effect the optional
Sensor Slide Adjust has on the Heating and
Cooling Setpoints
