Section 3 Auto-Zone Plus
3-34 Programming
Status Screen #3
Status Screen #4
Status Screen #5
CVAHU # 18 vl.xx
Supply Air.: 65.0°
Outdoor Air.: 70.2°
Wetbulb Temp: 0.0°
Line 2 -
Displays the current Supply Air Temperature.
Line 3 -
Displays the current Outdoor Air Temperature.
Line 4 -
Displays the current Wetbulb Temperature, if
available. This value is broadcast by a separate
Economizer Module.
CVAHU # 18 vl.xx
Economizer...: 10%
Heating Locked Out
Fan On
Line 2 -
Shows the current Economizer Damper position, if
the CVAHU has been configured to control the
Economizer.
(This line is blank if the CVAHU does not control
the Economizer)
Line 3 -
No Lockouts Active
Cooling Locked Out
Heating Locked Out
Line 4 -
Fan Off
Fan On
Heating Output.: OFF
Heating Output.: OFF
Cooling Output.: ON
Cooling Output.: ON
This screen shows how the relays were configured, either for
Heating or Cooling. The first line shows the status of Relay #2,
the second line shows Relay #3, etc.
The message will show ON/OFF status for that relay.
