Auto-Zone Plus Section 3
Programming 3-43
Zone Manager & CV AHU
Scheduling and Holidays
The Zone Manager and the Constant Volume AHU controllers both use the exact same
screens for programming. They also use the same method for calculating
Occupied/Unoccupied periods. All schedules are entered in 24-Hour Military Format.
See the Zone Manager or Constant Volume Menu Operations Screen for information on
how to access these programming functions.
Scheduling/Holiday Menu
Week Schedules
Schedule Start Time
Schedule Stop
Time
Zone Manager
1) Week Schedules
2) Holidays
ESC) Previous Menu
This menu appears whenever the user accesses the Scheduling
functions. It allows the user to choose between schedules or
holidays. Line 1 may read “Zone Manager” or Constant
Volume Unit” as application.
The screens will step through the Start Time and then the Stop
Time for each day of the week. You can quit at any point in the
process by pressing the "ESC" key.
All times are in 24-hour format, so 5:00 PM would be entered
as 1700.
If both the Start and Stop Times are ZERO, the schedule is in a
Continuous OFF mode.
If both the Start and Stop Times are 2359, the schedule is in a
Continuous ON mode.
WEEK SCHEDULES
Sunday Start Time
Value Hrs/Mins: 0
(MILITARY FORMAT)
WEEK SCHEDULES
Sunday Stop Time
Value Hrs/Mins: 0
(MILITARY FORMAT)
