Auto-Zone Plus Section 3
Programming 3-27
Zone Manager Setpoints
Control Setpoints
Setpoint Screen #1
Setpoint Screen #2
Cooling Lockout
If the outside air temperature drops 1° below this setpoint the
mechanical cooling is disabled. Cooling is re-enabled at 1°
above this setpoint.
Heat1 Lockout
If the outside air temperature rises 1° above this setpoint the
first stage of heat is disabled. The first stage of heat is re-
enabled at 1° below this setpoint.
Heat2 Lockout
If the outside air temperature rises 1° above this setpoint the
any heating stages of heat are disabled. If the outside air
temperature drops 1° below this setpoint any heating stages
above the first are re-enabled.
DUCT STATIC SETPOINT
Static Press: 0.5"
This screen will be displayed to allow you to enter the
controlling duct Static Pressure Setpoint.
Minimum Default Maximum
Static Press 0.1" 0.5" 2.0"
LOCKOUT SETPOINTS
Cool Lockout: 0°
Heat1 Lockout: 65°
Heat2 Lockout: 45°
The Mechanical Cooling and Heating Lockouts are entered on
this screen.
Minimum Default Maximum
Cool Lockout -40°F 50°F 80°F
Heat1 Lockout 30°F 65°F 99°F
Heat2 Lockout 30°F 45°F 99°F
