Section 3 Auto-Zone Plus
3-26 Programming
Configuration Screen #5
Configuration Screen #6
Note If no External Scheduler is used, enter a " 0 " for the Schedule!
Configuration Screen #7
BYPASS Act: Direct
Use Left/Right Arrow
Zone Manager
Uses Schedule #: 0
0 = Internal Clock
1-7 = External Clock
The Zone Manager normally uses its own real-time clock and
an internal week schedule to determine the
Occupied/Unoccupied mode of operation. The Zone Manager
does have the ability to use a global broadcast from another
scheduling device on the communications loop if a more
powerful schedule is required. If an external schedule is used,
the range of schedule numbers is 1 to 7.
Press < - > To Force
ReCalibration Of The
Static Pr. Sensor OR
ENTER to Skip This.
The Zone Manager only calibrates the static pressure sensor
one time. This occurs on the initial powerup, so it is vital that
the sensor be attached before the system is ever powered up. If
you were not able to do this, or accidentally activated the
system before the sensor was available, you can force it to
restart and calibrate the Static Pressure Sensor by pressing the
Minus Sign key. If you don't need to re-calibrate, simply press
the Enter or Down arrow key to skip over this item.
The Zone Manager Bypass Damper normally opens in a
clockwise direction. If your bypass damper opens in a
counter-clockwise direction, select reverse acting instead
of direct acting operation. To toggle between the two
modes, use the Left/Right Arrow Keys.
