Setpoint Screen #3
Setpoint Screen #4
Setpoint
Screen #5
Cool Staging: 4 Min
Min Cool Off: 4 Min
Heat Staging: 4 Min
Min Heat Off: 4 Min
The heating and cooling stages must have been off for a
minimum amount of time before they can be activated or re-
activated. As each additional stage of heating or cooling is
added, a minimum Staging Delay period must be satisfied,
between each additional stage required.
Minimum Default Maximum
Cool Staging 1 Min 4 Min 30 Min
Min Cool Off 1 Min 4 Min 30 Min
Heat Staging 1 Min 4 Min 30 Min
Min Heat Off 1 Min 4 Min 30 Min
Heat/Cool Changeover
Interval....: 10 Min
If the Zone Manager needs to change HVAC Modes between
heating and cooling, a Changeover Delay time must be
satisfied first. This prevents "Chasing" due to alternate hot and
cold air always being supplied to the zones after short
intervals.
Minimum Default Maximum
Interval 1 Min 10 Min 30 Min
Economizer Setpoints
Closed Volts.: 0.0
Opened Volts.: 10.0
If the Zone Manager has been configured for Economizer
Control, this screen will appear. The user can set the voltages
required to open and close the damper. Some actuators use a 2-
10 vdc signal instead of 0-10 vdc.
If the system is not configured for Economizer Control, no
economizer setpoint screens will appear.
Minimum Default Maximum
Closed Volts 0.0 VDC 0.0 VDC 10.0 VDC
Opened Volts 0.0 VDC 10.0 VDC 10.0 VDC
