WattMaster Auto-Zone Plus - Page 82

Section 3 Auto-Zone Plus
3-14 Programming
Status Screen #4
Status Screen #5
Zone # 1 v1.xx
Auxiliary Heat Off
Series Fan On
Line 2 -
No Auxiliary Heating - Aux Heating
Board Not Installed
Auxiliary Heat Off
Box Heating On
Aux Heating On
Box & Aux Heat On
Line 3 -
Series Fan On
or
Blank Line if Fan is Off
Line 4 -
Parallel Fan On
or
Blank Line if Fan is Off
Zone # 1 v1.xx
Damper O.K.
Zone Sensor O.K.
Line 2 -
Damper O.K.
Damper Feedback Fail
Damper Fail Opening!
Damper Fail Closing!
Line 3 -
Zone Sensor O.K.
Zone Sensor Failure
Line 4 -
Blank Line
