Section 3 Auto-Zone Plus
3-22 Programming
Status Screen #3
Status Screen #4
Status Screen #5
Manager # 1 vl.xx
Static Pr..: 0.49"
Bypass Dmpr: 18 %
Economizer.: 50 %
The Static Pressure, measured in Inches of Water Column, is
displayed along with the Bypass Damper position currently
being used to maintain that amount of static.
The last line shows the Economizer Damper position if your
system is configured for Economizer Control.
Manager # 1 vl.xx
Active Cool Stage: 0
Active Heat Stage: 0
The current quantity of active heating or cooling stages is
displayed on this screen. There are a maximum of six stages of
heating and six stages of cooling available, if the optional relay
expansion board is used.
Manager # 1 vl.xx
Cool Total.: 0.0°F
Heat Total.: 0.0°F
Mavericks..: 0
As the Zone Manager polls its Zone Controllers, it totals up the
heating and cooling demand so it can make an HVAC decision.
The Cooling Total and Heating Total are displayed on this
screen.
The Zone Manager also knows if any units have had a four
degree demand for at least one hour. It totals them up and
displays this value as the total number of Mavericks.
