WaveShark Foil - Connect Wings to Wing Pole; Install the Battery

14
EN
•
Connect cruiser/sport wing and wing pole
1) As shown in the gure below, x the front wing to the head of the wing pole with the screwdriver
(M5) and 3 screws (M6x40). Then, x the rear wing to the end of the wing with 2 screws (M6x22);
2) Firmly x the whole wing to the end of the mast with 2 screws (M6x30).
•
Connect race wing and wing pole
1) As shown in the gure below, x the front wing to the head of the wing pole with the screwdriver (M5) ,
screw (M6x30), and 2 screws (M6x22). Then, fix the rear wing to the end of the wing pole with
2 screws (M6x22);
2) Firmly x the whole wing to the end of the mast with 2 screws (M6x30).
Install the battery
The battery has been installed with a connector cover prior to delivery. Please remove it
before rst use, and restore the battery connector cover if for long-term storage.
1) Place the board on a at surface with the face upside;
M6*22
M6
*
40
M6*30
M6*22
M6
*
22M6
*
22
M6
*
30
M6*30
X
X
X
X
X
X
X
X
