15
November 2008 Part No. 920559 Rev H
Note:If for any reason the pulser is replaced, be sure the replacement pulser’s tabs snap
into place in the meter slots before tightening the two screws securing the pulser.
Figure 2-7 Meter Assemblies. The WIP and the XWIP are physically the same size, but have a different
colored case because they are not functionally interchangeable.
Xflo Meter
iMeter
Meter A
Meter B
Meter B
Meter A
Check Valve
Covers
XWIP
Dispenser
Front
Dispenser
Front
Pulser Connector
located inside of
cover
Pulser
(Side 1)
(Blue Case)
(Side 1)
(Side 2)
(Side 2)
To Next Page
