APPENDIX B INSTALLATION DRAWINGS
This revision of the manual includes new installation footprint drawings. These drawings show the location of
the conduits for entering the new smaller junction box, which will be standard production on Ovation dispensers
in November 2008.
New Junction Box
Previous Junction Box
