WBOX Technologies WBXRN080P8E User Manual

24
Specifications
Model
WBXRN040P4E
WBXRN080P8E
WBXRN160P8E
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming
bandwidth
40Mbps
80Mbps
80Mbps
Outgoing
bandwidth
80Mbps
Remote
connection
32
128
Video/Audio
output
Recording
resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)
HDMI/VGA output
1-ch, resolution:
1920 × 1080 /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Live view /
Playback
resolution
5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
4-ch@1080P
8-ch@720P, 6-ch@1080P
16-ch@4CIF, 12-ch@720P,
6-ch@1080P
Hard disk
SATA
1 SATA interface for 1
HDD
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
USB interface
1 × USB 2.0 and 1 × USB 3.0
Alarm in/out
(Optional)
4 / 1
PoE
Interface
4 independent 100 Mbps
PoE network interfaces
8 independent 100 Mbps PoE network interfaces
Max. Power
50W
120W
Supported
standard
AF and AT
General
Power supply
48V DC
100~240V AC
Consumption
(without hard disk
and PoE)
≤10W
Working
temperature
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
Working humidity
10 % ~ 90 %
Chassis
1U chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
315 × 230 × 45mm
(12.4"×9.1"×1.8")
445 × 290 × 45mm (17.5" × 11.4" × 1.8")
Weight
(without hard disk)
≤ 1 kg (2.2 lb)

WBOX Technologies WBXRN080P8E Specifications

General

Brand	WBOX Technologies
Model	WBXRN080P8E
Category	DVR
Language	English
