Webasto Thermo Top C Installation Documentation

7
Peugeot 207 / 207 SW / 207 CC
Wire sections 5, 7, and 10 for connection
K3.1 relay.
Wire sections
6 and 8 for connection IPCU.
Wire section
9 for connection K3.
Cutting
wires to
length
Produce connections as shown in wiring dia-
gram.
Install wire section
9 in protective sleeving
provided.
Premount-
ing K3 re-
lay
Produce connections as shown in wiring dia-
gram.
Premount-
ing K3.1 re-
lay
Produce connections as shown in wiring dia-
gram.
Premount-
ing K3.2 re-
lay
300
sw 0,5mm²
br 0,5mm²
3000
gn/ws 0,75mm²
5 6
7 8
9
200 200
10
86
85 30
87a87
K3
br sw
rt/ws
9
gn/ws
gn/ws
86
85 30
87a87
K3.1
3
rt
5
swbr
7
4
rt
10
br
1
rt
86
85 30
87a87
K3.2
2
rt
