Webasto Thermo Top C Installation Documentation

8
Peugeot 207 / 207 SW / 207 CC
Produce connections as shown in wiring dia-
gram.
The IPCU included in the kit is pre-pro-
grammed with the following settings:
Duty cycle: 75%
Frequency: 2000Hz
Voltage: 10V
Function: Low-side
The settings are to be checked during start-
up of heater, and adjusted if necessary.
Premount-
ing IPCU
86 85
A
E
IPCU
6
sw
br
8
A
15
86
85
E
