| Technical Data
4.3
Technical Data -
Enclosure
Box
NOTE
Drawing not to scale.
Fig. 1: Enclosure Box Dimensions
4.4
Technical Data -
Mounting Plate
NOTE
Drawing not to scale.
Fig. 2: Mounting Plate front view
