Webasto Thermo Top P Installation Documentation

1314084D_EN
14
Skoda Superb
1 Intake silencer
2 Combustion air pipe
3 27 mm dia. clamp
Premount-
ing com-
bustion air
pipe
Premounting exhaust pipe
1 Exhaust pipe
a = 365
2 Exhaust end section
b = 125
Discard section
X
Preparing
exhaust
pipe
1
Exhaust silencer
2 M6x20 bolt, large diameter washer, M6
flanged nut
3 Angle bracket
Premount-
ing ex-
haust
silencer
1
M6 flanged nut
Premount-
ing ex-
haust
system
23
1 2
3
a b
1 2
X
1
24
23
25
1
