Webasto Thermo Top P Installation Documentation

Skoda Superb
1314084D_EN
3
Heater / Installation Kit
To be ordered extra:
Also required for Climatronic:
Heater recommended for the respective vehicle class:
The selection of the heater is based on the passenger compartment size of the vehicle and the level of
comfort required by the customer!
Foreword
This installation documentation applies to Skoda Superb Diesel - Common Rail with direct shifting
transmission (DSG) vehicles - for validity, see page 2 - from model year 2008 and later, assuming tech-
nical modifications to the vehicle do not affect installation, any liability claims excluded. Depending on
the vehicle version and equipment, modifications may be necessary during installation with respect to
this installation documentation.
However, the stipulations in this "installation documentation", the "operating instructions" and the "in-
stallation instructions" for the Thermo Top C/P/E must always be observed.
The corresponding rules of technology and any information from the vehicle manufacturer should be
observed during the installation work.
General Instructions
Installation should be carried out according to the general, standard rules of technology. Unless spec-
ified otherwise, fasten hoses, lines and wiring harnesses to original vehicle lines and wiring harnesses
using cable ties. Insulate loose wires and tie back.
Sharp edges should be fitted with rub protection (split-open plastic hose).
Spray unfinished body areas, e.g. drilled holes, with anti-corrosion wax (Tectyl 100K, Order No. 111329).
Check or adjust the corresponding settings before installing an IPCU!
Special Tools
- Torque wrench for 2.0 - 10 Nm
- Hose clamping pliers
- Hole saw 42mm dia.
Quantity Description Order No.:
1 Retail accessories with desired heater control See price list
1 Installation kit for Skoda Superb Diesel - Common Rail with
direct shifting transmission (DSG)
1314083B
Quantity Description Order No.:
1 Additional bracket Skoda No.: 1Z0 810 679
2 Bolt Skoda No.: N90 749 003
1 Quick-release coupling VAG No.: 3B0 122 291 B
Quantity Description Order No.:
1 IPCU Kit for Climatronic 9013645A
Vehicle Heater
Compact car Thermo Top E
Mid-size car, estate car Thermo Top C
Full-size car, van, Offroader Thermo Top P
