Webasto Thermo Top P Installation Documentation

Skoda Superb
1314084D_EN
8
Climatic fan controller
Wiring dia-
gram
Webasto components Vehicle components Colours and symbols
Legend
HG Heater TT-C/E V2 Fan motor rt red
X1 6-pin heater connector N24 Resistor group ws white
F3 Fuse, 25 A J301 A/C control panel sw black
K3 Fan relay T... Plug connections br brown
SC40 Fuse, 40A gn green
Detach wire end from
SC40
X Cutting point
Wiring colours may vary.
Webasto
31
30
75
Skoda
F3
86
85 30
87a87
K3
HG
X1
4
SC
40
gn/ws
rt/ws
br
4²
rt
sw/rt
sw/rt
J301
T5h
3214
5
T5h
rt/ws
4²
sw
N24
3241
T4ac
12
V2
M
rt/sw
br
rt/
sw
rt/
sw
br
2
T10j
1
4²
4²
!
