GAS INSTRUCTIONS
LEAK-CHECK PREPARATION
m WARNING: The gas connections of your SUMMIT gas grill have
been factory-tested. We do, however, recommend that you leak-
check all gas connections before operating your SUMMIT gas
grill.
Remove Control Panel
Tools needed: Screwdriver, pliers, and towels.
A) Remove burner control knobs (1).
B) Open both doors. With a screwdriver, remove screws from the underside of control
panel (2).
C) Lift and remove battery housing located inside grill cabinet (3).
D) Using needle-nose pliers, disconnect wire terminals from the top of battery housing
(4). Do not pull on the wires; remove them by pulling on the wire terminals.
E) Place towels on the tops of both door assemblies. This will protect control panel and
door assemblies from getting scratched on next step.
F) Tilt bottom of control panel forward. Lift slightly (5) and then rotate it face down to
rest on tops of door assemblies. (Be careful not to break or disconnect wires for the
control panel LEDs.)
G) Carefully pull battery wires out from the inside of the grill cabinet (6).
H) Fully open right door. Place control panel on floor, leaning against towel covering right
door assembly (7).
2
3
4
6
7
1
5
The grills illustrated
in this Owner’s Guide
may vary slightly from
the model purchased.

Weber Summit E-670 Specifications

General

Type	Barbecue
Heat source	Propane/butane
Total power	- W
Ignition system	Snap-Jet
Adjustable thermostat	Yes
Side burners quantity	1
Number of cooking zones	6 zone(s)
Form factor	Cart
Product color	Black
Housing material	Stainless steel
Top surface type	Grate
Built-in capability	No
Cooking surface shape	Rectangular
Cooking surface (W x D)	805 x 490 mm
LED indicators	Temperature
Number of wheels	4 wheel(s)
Sear station power	3000 W

Weight and Dimensions

Depth	680 mm
Width	1890 mm
Height	1450 mm
Weight	157000 g
