Wega WEGACONCEPT Series - Machine Description and Components; Component Identification

9
Wegaconcept
User manual
ENGLISH
4 Description of the machine
4.1 Description
Cup heater surface.1.
Push-button panel for co ee selections.2.
Display and browser key.3.
Machine power switch.4.
Steam knob.5.
Anti-burn rubber.6.
Steam nozzle.7.
Tray and cup support grille.8.
Pull-out cup support grille.9.
Illuminated side.10.
Porta lter.11.
Hot water delivery nozzle.12.
Steam delivery nozzle/autosteamer (*).13.
Adjustable foot.14.
Push-button panel for services/ autosteamer (*).15.
Dispensing spouts.16.
Dispensing compartment light.17.
USB socket (for technical service only)18.
(*) optional.
1 5 182
13
6
5
107 68 91514
11
12
4
16 1617
3
