Weider Pro 250x - PART IDENTIFICATION CHART; Small Parts Identification Guide

5
M6 x 16mm Screw (28)
M6 x 20mm Screw (35)
M4 x 16mm Self-tapping Screw (42)
M5 x 10mm Self-tapping Screw (34)
M8 x 67mm Bolt (27)
M8 x 88mm Bolt (30)
M8 x 20mm Bolt (40)
M8 x 77mm Bolt (48)
M8 Nylon Locknut (33)
M6 Nylon Locknut (36)
M20 x 25mm Bolt (31)
M20 Washer (32)
M4 Washer (49)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST on page 14. Note: Some small parts may have been
pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
