3 Device description
1
2
3
4
5
6
7
8
9
10
11
12
13
Figure 3.1 Overview of the printer
1 “Device switched on” LED
2 Display
3 Peripheral interface
4 Flap
5 Cover
6 Inside margin stop
7 Outside margin stop
8 Reel holder
9 Top transfer ribbon unwinder
10 Top transfer ribbon winder
11 Print mechanism
12 Bottom transfer ribbon unwinder
13 Bottom transfer ribbon winder
14 MultiMark Plus Perforator perforation cutter
14
Figure 3.2 Device version with perforation cutter
