Device description
2967530000/00/06.20238
3.1 Technical data
General data
Ambient temperature
Operation +5°C to 40°C
Storage 0 °C to +60 °C
Transport -25 °C to +60 °C
Humidity
Operation 10 % to 85 %, non-condensing
Storage/transport 20 % to 85 %, non-condensing
Max. operating altitude 2000 m above sea level
Continuous sound pressure level < 70 dB (A)
Dimensions (WxHxD) 248 x 395 x 594 mm (9.76" x 15.55" x 23.39")
Weight 21 kg (46.30 lbs)
Supply voltage 100 to 240 V AC; 50/60 Hz, PFC
Interfaces RS232-C: 1.200 ... 230,400 baud/8 bit
1 x USB 2.0 Hi-Speed Device for PC connection
Ethernet 10/100 Mbit/s
1 x USB host on the control panel
2 x USB host at the rear
Control panel Touch screen, LCD colour display 4.3″ / 272 x 480 px
Printers
Print technology Thermal transfer
Printing resolution 300 dpi
Printing speed 40 to 150 mm/s
Print width Max. 100 mm
Material guidance Centred
