Installation Section 2
RATED VOLTAGES, CYCLES, PHASES, WATTAGE, AMPERAGES & POWER CORD CHART
Units with plugs are supplied with approximately six (6) to ten (10) foot cords.
Model Voltage, Cycle, Phase Watts Amps Plug
UHCTHD6 200-240V, 50/60H, 1Ph 2400-2900 12.0 320P6W/316P6/31-38015
UHCTHD3 200-240V, 50/60H, 1Ph 1670-2400 8.3-10.0 320P6W/316P6/31-38015
Weight of Equipment
Model Weight
UHCTHD6 195.6 lbs (88.7kg)
UHCTHD3 120lbs (54kg)
Clearance Requirements
DANGER
Minimum clearance requirements are the same for
noncombustible locations as for combustible locations.
The flooring under the appliance must be made of a
noncombustible material.
DANGER
Risk of fire/shock. All minimum clearances must be
maintained. Do not obstruct vents or openings.
Sides/Back 1.0” (25mm)
Dimensions
Model Width Depth Height
UHCTHD6
22.2”
(56.3cm)
25.8”
(65.4cm)
26.0”
(66.0cm)
UHCTHD3
22.2”
(56.3cm)
25.8”
(65.4cm)
16.6”
(42.2cm)
Electrical Service
DANGER
Check all wiring connections, including factory
terminals, before operation. Connections can become
loose during shipment and installation.
DANGER
Copper wire suitable for at least 167°F (75°C) must be
used for power connections.
n
Warning
All units should be connected to a grounded power
supply system.
n
Warning
This appliance must be grounded and all field wiring
must conform to all applicable local and national
codes. Refer to rating plate for proper voltage. It is the
responsibility of the end user to provide the disconnect
means to satisfy the authority having jurisdiction.
n
Warning
All electrically operated appliances must be electrically
grounded in accordance with local codes, or in the
absence of local codes, with national electric code,
ANSI/NFPA NO. 70-1990.
n
Warning
This appliance is equipped with a three-prong
grounding plug for your protection against shock
hazard and must be plugged into a properly grounded
three-prong receptacle. DO NOT cut or remove the
grounding prong from this plug.
VOLTAGE
All electrical work, including wire routing and
grounding, must conform to local, state and national
electrical codes. The following precautions must be
observed:
• The equipment must be grounded.
• A separate fuse/circuit breaker must be provided
for each unit.
• A qualified electrician must determine proper
wire size dependent upon location, materials
used and length of run (minimum circuit ampacity
can be used to help select the wire size).
• The maximum allowable voltage variation is ±10%
of the rated voltage at equipment start-up (when
the electrical load is highest).
• Check all green ground screws, cables and wire
connections to verify they are tight before start-
up.
