CM2P201 User Guide
97
Click the Apply button on the right side to make the change take effect.
Name
Range
Name
Range
Symbol Rate (KBaud)
5057 (QAM64)
5361 (QAM256)
PSI/SI Interval (ms)
50~10000
RF level
25~45dBmV/85~105dBμV
Frequency (KHz)
48000~862000
QAM Mode
QAM64/256
CM2-QAMB-R01>Service Configuration
 TS setting: Please refer to IP output service configuration.
 LCN setting: You need to add NIT streams of all frequencies to the base TS (frequency), which
is for your STB to automatically search and identify all the TS (frequencies) LCN information.
 Check or reset Original Network ID and TS ID of each TS (frequency)., Each TS should have
different IDs.
 Fill the Original Network ID and TS ID of each TS (frequency) in the field of the base TS
(frequency) and then click Add to create a NIT stream for this TS (frequency).
 Click +Descriptor then LCN Descriptor to check all the programs which are contained in this
frequency. Then set programs LCN.
