DMP900 User Guide
60
Name
Range
Name
Range
Video Source
SDI, CVBS
GOP Structure
IBBP/IPPP/IBP
Video Encoder Type
H264, MPEG2
GOP Size
6~63
Video Encode Rate
600~15000
GOP Close
Disable, Enable
Video Encode Mode
CBR, VBR
Aspect Ratio
Auto
Audio Source
SDI1-Audio1/2(SDI)
SDI1-Audio3/4(SDI)
SDI1-Audio5/6(SDI)
L1-XLR1-R1(CVBS)
No Audio
Video Standard
Auto
HD_DOWNSCALE_720x576i50
HD_DOWNSCALE_720x480I60
HD_DOWNSCALE_704X480I60
HD_DOWNSCALE_544X480I60
Video Min Encode
0~3000
PCR PID
32~8190
Video Max Encode
Rate (Payload)Kbps
6000~8000
Video PID
32~8190
Audio Encoder Type
AC3, MPEG1_Layer2
MPEG2_AAC
MPEG4_AAC
PMT PID
32~8190
AC3 AC Mode
1+1(L,R)
Service ID
1
Audio Encode Rate
64~384
Program Name
Program-x
Belong To
Program x/ None
Provider Name
Encoder
Volume(dB)
0~4
Latency Adjustment
-500~3000
Audio PID
32~8190
VLC Mode
CABAC, CAVLC
Audio Source
L1-XLR1-R1, No
Audio
Profile
Main, High
Audio Encoder Type
MPEG1_Layer2
Level
3.0, 3.1, 3.2, 4.0, 4.1, 4.2
Audio Mode
Stereo/Dual/Mono
Sample Rate
48KHz
Audio Encode Rate
64~384
Brightness(0~255)
0~255
Belong To
Program x/ None
Contrast (0~255)
0~255
Volume(dB)
0~4
Saturation(0~255)
0~255
Audio PID
32~8190
Hue(-180~180)
-180~180
Same PID for PCR
and Video
Yes/No
