WELLTECH ATA-172 - Page 73

ATA Web user guide
73 / 114 2015/1/8
Item Description
Provide options: General, Asterisk, BroadWorks, Nortel, Xener,
Vodtel, SKTelink.
* Please make sure which model of SIP Server or IP-PBX server
for Wellgate M1 to work with in order to select suitable SIP
Server Type.
Use user=phone
(Register)
Default: Disable; When this function is on, the Register Header
will add ”user=phone” message in Register packages.
Provide options: Disable, Enable.
*This function must be supported from SIP Server.
Use user=phone
(Invite)
Default: Disable; When this function is on, the Invite Header will
add ”user=phone” message in Invite packages.
Provide options: Disable, Enable.
*This function must be supported from SIP Server.
Send SIP PRACK
of Proxy
Default: Disable; When this function is on, there will add “PRACK
Header” messages.
Provide options: Disable, Enable.
*This function must be supported from SIP Server.
Only Accept
Trusted
Certificates
Default: Enable. Set up IP incoming call if it comes from trusted
SIP Server or IP-PBX or not.
When Enable, this device only accept IP incoming call from
trusted SIP Server or IP-PBX. It will reject P2P call.
When Disable, this device accept P2P call. And accept any IP
incoming call even from not trusted SIP Server or IP-PBX.
Provide drop-down options: Disable, Enable.
Set up User
Agent Content
Default: (null); When send SIP packets, the packets header
“User-Agent” message will join this word. This column can enter
numbers and strings (support: 0~9, a~z, @, _, -, *, #, ., +, :, ()
[, ] and blank); maximum length is 46 bytes.
Submit [Button] Save the Settings.
9.3.3
Operate Instuction
Example 1: SIP Expire Time
 SIP Expire Time: 60
Step 1: In [Service Domain Setting] web page, Set up [Realm Active: Enable, Display
Name: 22061, Phoner Number: 22061, Authentication ID: 22061, Authentication
Password: test, Domain Server: 61.62.236.71:6000, Proxy Server:
61.62.236.71:6000, Subscribe for MWI: Disable] (See Figure 1).
