ATA Web user guide
82 / 114 2015/1/8
10.2 Auto Configuration
10.2.1 Function
Provide 3 kind of provision methods. (TFTP, FTP and HTTP)
10.2.2 Instruction
Item Decription
Provision Active Default: Disable; When this function is on, LP399 will download
the MACID.dat from the designated Server.
Provide options: Disable, TFTP, FTP and HTTP.
2 Steps
Configuration
Default: Disable; Set up 2 Steps configuration, get the common
settings first, then get the SIP accounts and passwords
secondly.
Provide options: Disable, Enable.
*This function must be supported from SIP Server.
Server Auto
Discovery
Default: Disable; DHCP TFTP Option 66 (TFTP): DHCP Server will
offer the Option 66 Server IP address into the column of system
[TFTP Server] when it assigns IP.
Broadcasting: Discovering the Server by broadcasting, the
Server will send the information of Type and Server to LP399, it
will fill in these information to the corresponding columns.
Provide options: Disable, DHCP TFTP Option 66 (TFTP),
To Next Page
