EXPLODED VIEW & PARTS LIST
PART NO. DESCRIPTION
QTY. PART NO. DESCRIPTION QTY.
3962-001 Blade tension knob 1 3962-054
Tracking lock knob
1
3962-002 Bushing 1 3962-055 Guide block 2
3962-003 Retaining ring 1 3962-056 Pan head screw 2
3962-004 Frame cap 1 3962-057 Lock nut 2
3962-005 Spring 1 3962-058
Cover lock knob
2
3962-006 Nut 1 3962-059
Socket head bolt
2
3962-007 Retaining ring 2 3962-060 Shaft 1
3962-008 Shaft 1 3962-061 Gear 1
3962-009 Guide plate 2 3962-062 Knob insert 1
3962-010 Pulling plate 1 3962-063
Upper guide adjusting knob
1
3962-011 Hex head bolt 4 3962-064 Spring 1
3962-012 Flat washer 8 3962-065 Lock knob 1
3962-013 Hex nut 4 3962-066 Lower guard 1
3962-014 bevel block 1 3962-067
Socket head bolt
2
3962-015 Shaft 1 3962-068 Shaft 1
3962-016 Ball bearing 4 3962-069 Hex nut 4
3962-017 Retaining ring 4 3962-070 Hex head bolt 4
3962-018 Upper wheel 1 3962-071
Thread forming screw
2
3962-019 Retaining ring 2 3962-072 Limiting plate 1
3962-020 Tyre 2 3962-073
Upper blade guard
1
3962-021 Blade 1 3962-074 Rack 1
3962-022 Upper cover 1 3962-075 Sliding cover 1
3962-023 Lower cover 1 3962-076
Socket head bolt
1
3962-024 Nut 2 3962-077
Connecting shaft
1
3962-025 Bushing 2 3962-078 Support block 1
3962-026 Socket head bolt 2 3962-079 Set screw 1
3962-027 Frame 1 3962-080
Thread forming screw
1
3962-028 Nut 1 3962-081 Knob 1
3962-029 Flat washer 1 3962-082 Flat washer 1
3962-030 LED driver 1 3962-083 Bearing cover 1
3962-031 Socket head bolt 1 3962-084 Shaft 1
3962-032 Serrated washer 2 3962-085 Ball bearing 1
3962-033 Pan head screw 2 3962-086 Knob 1
3962-034 Switch box 1 3962-087
Socket head bolt
2
3962-035 Connecting terminal 2 3962-088 Flat washer 2
3962-036 Switch cover 1 3962-089 Shaft 2
3962-037 LED switch 1 3962-090 Ball bearing 2
3962-038 Main switch 1 3962-091 Hex nut 1
3962-039 Pan head screw 2 3962-092 Ball bearing 1
3962-040 Nut 1 3962-093
Socket head bolt
1
3962-041 Flat washer 1 3962-094 Nut 2
3962-042 Bushing 1 3962-095
Lower guide plate
1
3962-043 Flat washer 1 3962-096 Bushing 2
3962-044 Brush 1 3962-097 Ball bearing 2
3962-045 Carriage blot 1 3962-098
Socket head bolt
2
3962-046 Hex nut 1 3962-099
Socket head bolt
2
3962-047 Spindle pulley 1 3962-100 Flat washer 2
3962-048 Socket head bolt 3 3962-101 Hex nut 2
3962-049 Cord bushing 2 3962-102
Socket head bolt
2
3962-050 Limiting shaft 1 3962-103 Set screw 1
3962-051 Hex nut 1 3962-104 Motor pulley 1
3962-052 Knob cap 1 3962-105 Belt 1
3962-053 Tracking set knob 1 3962-106 Hex head bolt 4

Wen 3962 Specifications

General

Motor	3.5 Amp
Weight	42 lbs
Type	Band Saw
Blade Diameter	Not Applicable
Arbor Size	Not Applicable
Table Size	14-1/4" x 12-1/2"
Max Cutting Depth at 45°	Not Applicable
