Wen 3962 Manual

19
EXPLODED VIEW & PARTS LIST
PART NO. DESCRIPTION
QTY. PART NO. DESCRIPTION QTY.
3962-107 Motor support plate 1 3962-142 LED light 1
3962-108 Flat washer 2 3962-143 Knob 2
3962-109 Socket head bolt 2 3962-144 Flat washer 2
3962-110 Key 1 3962-145
Fence support cap
2
3962-111 Motor 1 3962-146 Fence support 1
3962-112 Thread forming screw 3 3962-147 Guide plate 1
3962-113 Dust port 1 3962-148 Carriage blot 2
3962-114 Dust port cover 1 3962-149 Fence 1
3962-115 Pin 1 3962-150 Guide rail cap 1
3962-116 Power cord 1 3962-151 Guide rail 1
3962-117 Guide rail lock knob 4 3962-152 Guide rail cap 1
3962-118 Table insert 1 3962-153
Thread forming screw
2
3962-119 Table 1 3962-154 Pointer 1
3962-120 Miter gauge 1 3962-155 Sliding base 1
3962-121 Pan head screw 1 3962-156 Nut 3
3962-122 Flat washer 1 3962-157 Spacer 1
3962-123 Pointer 1 3962-158
Socket head bolt
1
3962-124 Lock nut 1 3962-159 Spring plate 1
3962-125 Flat washer 2 3962-160 Pan head screw 1
3962-126 Angle guide plate 2 3962-161 Lock block 1
3962-127 Bushing 2 3962-162 Lock handle 1
3962-128 Table bevelling base 1 3962-163 Shaft 1
3962-129 Carriage blot 2 3962-164 Hex nut 16
3962-130 Flat washer 4 3962-165 Flat washer 16
3962-131 Hex head bolt 4 3962-166 Carriage blot 16
3962-132 Flat washer 4 3962-167 Leg 4
3962-133 Hex head bolt 4 3962-168 Long brace 2
3962-134 Lock handle 1 3962-169 Short brace 2
3962-135 Hex head bolt 1 3962-170 Foot 4
3962-136 Hex nut 1 3962-171 Open spanner 1
3962-137 Nut 1 3962-172
6mm hex wrench
1
3962-138 Flat washer 1 3962-173
5mm hex wrench
1
3962-139 Cord clamper 1 3962-174
4mm hex wrench
1
3962-140 Socket head bolt 1 3962-175
3mm hex wrench
1
3962-141 Hex nut 1

Wen 3962 Specifications

General

Motor	3.5 Amp
Weight	42 lbs
Type	Band Saw
Blade Diameter	Not Applicable
Arbor Size	Not Applicable
Table Size	14-1/4" x 12-1/2"
Max Cutting Depth at 45°	Not Applicable
