Wen 3975 User Manual

13
No. Part Description Qty.
49 3975-049 Tube 1
50 3975-050 Guide plate 2
51 3975-051 Socket head screw 4
52 3975-052 Socket head screw 2
53 3975-053 Lock washer 2
54 3975-054 Set screw 1
55 3975-055 Sliding block 1
56 3975-056 Blade 1
57 3975-057 Bevel plate 1
58 3975-058 Ball bearing 2
59 3975-059 Retaining ring 1
60 3975-060 Rear blade wheel 1
61 3975-061 Flat head screw 1
62 3975-062 Key 1
63 3975-063 Front blade wheel 1
64 3975-064 Flat washer 1
65 3975-065 Flat head screw 1
66 3975-066 Frame 1
67 3975-067 Spring washer 8
68 3975-068 Blade tension knob 1
69 3975-069 Cord clamp 2
70 3975-070 Pan head screw 2
71 3975-071 Set screw 1
72 3975-072 Lock handle 1
73 3975-073 Flat washer 1
74 3975-074 Nut 4
75 3975-075 Lock washer 4
76 3975-076 Flat washer 4
77 3975-077 Rear blade guide block 1
78 3975-078 Ball bearing 2
79 3975-079 Flat washer 4
80 3975-080 Pin 1
81 3975-081 Socket head screw 1
82 3975-082 Lock washer 1
83 3975-083 Blade guard 1
84 3975-084 Flat washer 4
85 3975-085 Ball bearing 8
86 3975-086 Shaft 4
87 3975-087 Flat washer 2
88 3975-088 Lock washer 2
89 3975-089 Socket head screw 2
90 3975-090 Socket head screw 1
91 3975-091 Flat washer 1
92 3975-092 Guard plate 1
93 3975-093 Pin 1
94 3975-094 Front blade guide block 1
95 3975-095 Nut 1
96 3975-096 Hex head bolt 1
No. Part Description Qty.
97 3975-097 Nut 1
98 3975-098 Center shaft 1
99 3975-099 Torsion spring 1
100 3975-100 Lock handle 1
101 3975-101 Flat washer 1
102 3975-102 Swivel support 1
103 3975-103 Flat washer 1
104 3975-104 Nut 1
105 3975-105 Hex head bolt 1
106 3975-106 Nut 1
107 3975-107 Socket head screw 1
108 3975-108 Flat washer 1
109 3975-109 Socket head screw 2
110 3975-110 End stop washer 2
111 3975-111 Bushing 1
112 3975-112 Retaining ring 1
113 3975-113 Lock pin 1
114 3975-114 Pan head screw 2
115 3975-115 Angle scale 1
116 3975-116 Base 1
117 3975-117 Foot 4
118 3975-118 Carriage bolt 1
119 3975-119 Flat washer 1
120 3975-120 Nut 1
121 3975-121 Vise base 1
122 3975-122 Flat head screw 2
123 3975-123 Vise jaw 1
124 3975-124 Sliding case 1
125 3975-125 Retaining ring 1
126 3975-126 Screw 1
127 3975-127 Spring pin 1
128 3975-128 Bushing 1
129 3975-129 Handle cap 2
130 3975-130 Socket rod 1
131 3975-131 Handle rod 1
132 3975-132 Set screw 1
133 3975-133 Guide block 1
134 3975-134 Lock washer 1
135 3975-135 Hex head bolt 1
136 3975-136 Spring pin 2
137 3975-137 Lock washer 6
138 3975-138 Socket head screw 6
139 3975-139 Nut 1
140 3975-140 Work stop rod 1
141 3975-141 Work stop 1
142 3975-142 Lock handle 1
143 3975-143 Hex head bolt 1
EXPLODED VIEW AND PARTS LIST
No. Part Description Qty.
1 3975-001 Speed adjusting knob 1
2 3975-002 Circuit breaker 1
3 3975-003 Motor housing 1
4 3975-004 Thread forming screw 2
5 3975-005 Motor driver 1
6 3975-006 Pan head screw 3
7 3975-007 Pan head screw 1
8 3975-008 Serrated washer 1
9 3975-009 Motor assembly 1
10 3975-010 Socket head screw 4
11 3975-011 O ring 4
12 3975-012 Strain relief 1
13 3975-013 Switch 1
14 3975-014 Thread forming screw 2
15 3975-015 Switch box 1
16 3975-016 Indicator light 1
17 3975-017 Flat washer 2
18 3975-018 Thread forming screw 2
19 3975-019 Power cord 1
20 3975-020 Inner line 1
21 3975-021 Front wheel shaft 1
22 3975-022 Key 1
23 3975-023 Retaining ring 1
24 3975-024 50T Gear 1
25 3975-025 Ball bearing 2
26 3975-026 Retaining ring 2
27 3975-027 Oil seal 1
28 3975-028 Ball bearing 2
29 3975-029 Retaining ring 1
30 3975-030 43T Gear 1
31 3975-031 Key 1
32 3975-032 Pinion gear 1
33 3975-033 Spring pin 1
34 3975-034 Socket head screw 4
35 3975-035 Lock washer 4
36 3975-036 Gear box 1
37 3975-037 Frame cover 1
38 3975-038 Pan head screw 6
39 3975-039 Flat washer 6
40 3975-040 Left handle part 1
41 3975-041 Button 1
42 3975-042 Spring 1
43 3975-043 Operating switch 1
44 3975-044 Cord clamp 5
45 3975-045 Pan head screw 5
46 3975-046 Right handle part 1
47 3975-047 Thread forming screw 3
48 3975-048 Flat head screw 4
