Wen MM1215 User Manual

31
No. Part No. Description Qty.
3-01 MM1215-301
Cross-head Screw
M4X12
6
3-02 MM1215-302 Table Insert 1
3-03 MM1215-303 Spring 1
3-04 MM1215-304 Lock Nut 1
3-05 MM1215-305 Miter Lock Lever 1
3-06 MM1215-306
Cross-head Screw
M6X45
1
3-07 MM1215-307 Miter Depress Tab 1
3-08 MM1215-308 Sleeve 1
3-09 MM1215-309
Cross-head Screw
M5X35
1
3-10 MM1215-310 Pin 1
3-11 MM1215-311
Cross-head Screw
M4X12
3
3-12 MM1215-312 Miter Angle Pointer 1
3-13 MM1215-313 Knob 1
3-14 MM1215-314
Socket Screw
M8X35
1
3-15 MM1215-315 Washer 1
3-16 MM1215-316
Socket Screw
M6X30
2
3-17 MM1215-317 Hex Nut M6 2
3-18 MM1215-318 Bevel Angle Pointer 1
3-19 MM1215-319 Pin 1
3-20 MM1215-320 Spring 1
3-21 MM1215-321 Bevel Shaft 1
3-22 MM1215-322 Left Sliding Fence 1
3-23 MM1215-323 Right Sliding Fence 1
3-24 MM1215-324
Halt Round Screw
M6X20
4
3-25 MM1215-325 Spring Washer 4
No. Part No. Description Qty.
3-26 MM1215-326 Label 1
3-27 MM1215-327 Washer 4
3-28 MM1215-328 Knob 2
3-29 MM1215-329 Label 1
3-30 MM1215-330 Base Fence 1
3-31 MM1215-331 Miter Table 1
3-32 MM1215-332
Socket Screw
M8X20
1
3-33 MM1215-333
Cross-head Screw
M5X58
2
3-34 MM1215-334 Washer 2
3-35 MM1215-335 Knob 1
3-36 MM1215-336 Lock plate 1
3-37 MM1215-337 Square Nut M10 1
3-38 MM1215-338 Press plate 1
3-39 MM1215-339 Spring 1
3-40 MM1215-340 Table support foot 1
3-41 MM1215-341
Right Extension
Bar
1
3-42 MM1215-342
Cross-head Screw
M4X8
2
3-43 MM1215-343 Rubber Foot 4
3-44 MM1215-344 Spring 2
3-45 MM1215-345 Lock Block 1
3-46 MM1215-346 Lock Nut M5 2
3-47 MM1215-347 Lock Nut M8 1
3-48 MM1215-348 Miter Scale 1
3-49 MM1215-349 Base 1
3-50 MM1215-350 Left Extension Bar 1
3-51 MM1215-351 Knob 1
3-52 MM1215-352 Set Screw M6X6 1
EXPLODED VIEW & PARTS LISTEXPLODED VIEW & PARTS LIST
BASE AND TABLE ASSEMBLY
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
