12
Technical Data
3.4 Sonic Cone Diagrams
Measurement of sonic cone on plate 100×100 mm
Ob = object
Sc = sonic cone width
Standard Narrow Extra Narrow
Measurement of the sonic cone on a rod with a diameter of 25 mm
