Setup via IO-Link
Error
Short circuit A short circuit has occurred on at least one pin.
Device error A hardware error has occurred.
8.1.5 Simulation Functions
This function simulates the behavior of the sensor regardless of the current status and measured value. This
can be used to check whether a plant in which the sensor is integrated reacts correctly to the data supplied
by the sensor and processes them accordingly.
If a measured value is specified, the sensor behaves as if the specified measured value corresponds to the
actual measured value. This means that the behavior of the outputs and status messages is simulated ac-
cording to the specified measured value.
In addition, the individual outputs and status messages can be simulated separately from the measured
value.
Function Possible Settings Default
Simulation
Mode
On
Off
Off
Simulation
measured
value
Current measured value
min...max. measuring range
Current mea-
sured value
Simulation
SSC1
According to the measured value
On
Off
According to
the measured
value
Simulation
SSC2
According to the measured value
On
Off
According to
the measured
value
Simulation
status mes-
sages
Tests the individual status messages
According to the measured value
On
Off
According to
the measured
value
NOTE!
• Output O1 is used for IO-Link communication in this function and cannot be simulated.
• Simulation mode ends automatically as soon as the power supply is interrupted.
