Ultrasonic Sensors
5. Installation and Electrical Connection
5.1 Installation
• Protect the product from contamination during installation.
• Observe all applicable electrical and mechanical regulations, standards, and safety rules.
• Protect the product against mechanical influences.
• Make sure that the sensor is mounted in a mechanically secure fashion.
• If the object has smooth surfaces, the angle between the axis of the sound waves and the surface of the
object
should be 90° ±3°. The angle can be considerably larger in the case of rough object surfaces.
• The sensor’s sensing face must remain unobstructed.
NOTE!
Observe the blind spot.
In the area between the sensor’s active surface and the beginning of its working range,
correct functioning of the sensor is not assured. No objects may be located in this area.
Object position Switching posi-
tion / switching
LED
Error output /
error LED
Measured value,
IO-Link
Working range × Defined Defined Defined
Blind spot × Undefined Undefined Undefined
Above the
working range
× Defined Defined Defined
ATTENTION!
Risk of property damage in case of improper installation!
The product may be damaged.
• Installation instructions must be complied with.
CAUTION!
Risk of personal injury or property damage during installation!
Personal injury and damage to the product may occur.
• A safe installation environment must be assured.
