Default Settings
Required Action in Case of Fault:
NOTE!
• Shut down the machine.
• Analyze and eliminate the cause of error with the aid of the diagnostics information.
• If the error cannot be eliminated, please contact wenglor’s support department.
• Do not operate in case of indeterminate malfunctioning.
• The machine must be shut down if the error cannot be definitively explained
or properly eliminated.
DANGER!
Risk of personal injury or property damage in case of non-compliance!
The system’s safety function is disabled. Personal injury and damage to equipment may
occur.
• Required action as specified in case of fault.
6. Default Settings
Technical Data U1RT002 U1RT003
Sensor operating mode Normal
Filter 0
Sonic cone Standard
Process data Outputs and measured value
Temperature mode Internal
O1 pin function Switching output
O1 teach-in mode Foreground
O1 PNP/NPN PNP NPN
O1 NO/NC NO
O1 switching point 1200
O1 additional hysteresis 0
O2 pin function Switching output
O2 teach-in mode Foreground
O2 PNP/NPN PNP NPN
O2 NO/NC NO
O2 switching point 1200 mm
O2 additional hysteresis 0 mm
I3 function Teach-in input
