Ultrasonic Sensors
3. Technical Data
3.1 General Data
Order number
Technical Data
U1RT002 U1RT003
Ultrasound Data
Working range, Reflex Sensor 100…1,200 mm
Working range, Through-Beam Sensor 1…2,000 mm
Setting range 100…1,200 mm
Reproducibility 5 mm
Linearity deviation 2 mm
Resolution 1 mm
Ultrasonic frequency 240 kHz
Aperture angle < 12°
Service life (ambient temp. = +25° C) 100,000 h
Switching hysteresis 1% of the switching distance, at least 2 mm
Electrical Data
Supply voltage * 18…30 V DC
Current consumption (operating voltage = 24 V) ≤ 30 mA
Switching frequency, Reflex Sensor 7 Hz
Switching frequency, Through-Beam Sensor 7 Hz
Response time, Reflex Sensor 72 ms
Response time, Through-Beam Sensor 72 ms
Temperature range (during operation) −30…60 °C
Number of switching outputs 2
Switching output voltage drop < 2.5 V
Switching output switching current 100 mA
Short-circuit protection Yes
Reverse polarity and overload-proof Yes
Lockable Yes
Interface IO-Link, NFC
IO-Link version 1.1
Smart Sensor Profile Yes
Data Storage Yes
Protection class III
Mechanical Data
Setting method Teach-in, IO-Link, NFC
Housing material Plastic, PBT, ABS
Sleeve material Nickel-plated brass
Nut material Plastic, PA
Degree of protection IP67, IP68
* Start-up time: 650 ms
