Western Digital Ultrastar Data102 - PSU Layout

User Guide
3. Component Overviews
3.3 PSU Description
Specification Value
80 PLUS Standard Platinum
Input Voltage 200 - 240 VAC
Connector Type C14
Number per Enclosure 2
Part Number 1EX0434
Hot Swappable? Yes
FRU or CRU? CRU
Weight 1 kg / 2.2 lbs.
3.3.2 PSU Layout
Figure 21: Layout
Table 28: Exterior Components
Number Feature
1 Internal Connector
2 C14 Power Receptacle
3 Latch Release Lever
4 Fan
