Western Digital Ultrastar Data102 - IOM Fan Specifications; IOM Fan Layout

User Guide
3. Component Overviews
3.5 IOM Fan Description
Figure 24: Overview Image
The IOM Fan is designed to focus cooling on the enclosure's IOMs. It is installed in the central chassis bay
and is accessed from the top of the enclosure underneath the lid. It is attached to the chassis toolless
release mechanism that allows for easy replacement.
3.5.1 IOM Fan Specifications
Specification Value
Number per Enclosure 1
Part Number 1EX0432
Hot Swappable? Yes
FRU or CRU? CRU
Weight 181.4 g / .4 lbs
3.5.2 IOM Fan Layout
