4-16
REMOVING THE OVEN DOOR GASKET
1. Open the oven door to its fully open posi-
tion.
2. Remove the screw from the door gasket
bracket and remove the bracket from the
oven.
REASSEMBLY NOTE: When you install the
new gasket, make sure that all of the clips are
seated in their liner holes, and that the ends of
the gasket are pushed fully into their holes. Use
the pointed end of a pencil to push the gasket
ends into the holes.
Gasket Clips
Gasket Bracket
Screw
Door Gasket
3. Pull the ends of the gasket out of the liner
holes and pull the clips out of their liner
holes.
CAUTION: When you work on the double
oven, be careful when handling the sheet metal
parts. Sharp edges may be present, and you
can cut yourself if you are not careful.
To Next Page
