Whirlpool RBD306PD - Control Panel Test Locations (Tech Sheets 4451887 C;4451888 A)

6-5
COMPONENTS
FRONT/REAR
SERVICEABLE
CHECK POINTS RESULTS
Door Switch Front
P23-2 (BR) to
P23-1 (TAN)
Door Open =
Closed Circuit
Door Closed =
Open Circuit
Door Lock
Solenoid
Front
P25-1 (Y) to
P25-2 (GY)
80
Ω to 100 Ω
Oven
Temperature
Sensor
Front
Sensor
P23-4 (V) to P23-6
(GN)
1080
Ω
Blower Rear
P24-5 (GY) to
Neutral (W)
10
Ω to 15 Ω
Oven Shutdown
Thermal Fuse
Rear
P18-4 (R)
or P18-1 (R)
to Red Wire at
Terminal Block
Closed Circuit
Bake Element Front
P18-4 (R) to
Red Wire at
Terminal Block
25
Ω to 30 Ω
Broil Element Front
P18-1 (OR) to
Red Wire at
Terminal Block
45 Ω to 55 Ω
Convection Fan
Motor
Rear
P24-6 (OR) to
Neutral (W)
8
Ω to 12 Ω
Control Panel
Thermal Fuse
Front L1 (BK) to P24-3 (BK) Closed Circuit
Latch Switch Front
P23-3 (BU) to
P23-1 (TAN)
Door Unlocked =
Open Circuit
Door Locked =
Closed Circuit
Control
Transformer
Front
Primary Winding
P16-5 (R) to
P16-7 (R)
75
Ω to 95 Ω
Secondary Winding
P16-2 (BU) to
P16-3 (BU)
2
Ω to 4 Ω
LOWER OVEN UPPER OVEN
COMPONENTS
FRONT/REAR
SERVICEABLE
CHECK POINTS RESULTS
Door Switch Front
P23-7 (BR/W) to
P23-1 (TAN)
Door Open =
Closed Circuit
Door Closed =
Open Circuit
Door Lock
Solenoid
Front
P25-3 (Y/W) to
P25-4 (GY/W)
80
Ω to 100 Ω
Oven
Temperature
Sensor
Front
Sensor
P23-5 (V) to
P23-6 (GN)
1080
Ω @ 70 ° F @ 70 ° F
Blower Rear
P27-2 (GY) to
Neutral (W)
10
Ω to 15 Ω
Oven Shutdown
Thermal Fuse
Rear
P26-2 (OR)
or P26-4 (R)
to Red Wire at
Terminal Block
Closed Circuit
Bake Element Front
P26-4 (R) to
Red Wire at
Terminal Block
25
Ω to 30 Ω
Broil Element Front
P26-2 (OR) to
Red Wire at
Terminal Block
45 Ω to 55 Ω
Latch Switch Front
P23-8 (BU/W) to
P23-1 (TAN)
Door Unlocked =
Open Circuit
Door Locked =
Closed Circuit
CONTROL PANEL TEST LOCATIONS
TECH SHEETS 4451887C & 4451888A
