82
■
Shelf removal and installation
1. Unscrew the screw clockwise on the front end of the rail
2. Pull the shelf rails to the inside of the oven cavity and take them off at the front
3. To install the shelf firmly, insert it into the screw at the rear end, and then tighten the screw at the front end
anti-clockwise.
Note: Be sure to pay attention to the direction of
rotation when removing the front screw. Incorrect
disassembly can lead to locking of the front
screw connection and cause damage to the
structure, that the front-end screws will be
unable to be disassembled normally.
