www.whisperkool.com | Page 13
5. Lift the Evaporator Unit (Fan Coil Unit) up and place onto
the wall bracket.
6. Form the copper lines on the outside of the cellar in the
desired direction.
NOTE: WhisperKOOL recommends using sweep 90-degree
bends when making turns with the line set.
With the system operating, sight glass clear, and the
cellar close to 55 degrees Fahrenheit. Check the suction
pressure, the temperature of the suction line at the outlet
of the evaporator, and if necessary adjust the expansion
valve to bring the superheat level between 8-12 degrees.
NOTE: Be sure that the power cord
and drain line stay clear of the
bracket contact area
INSTALLING THE EVAPORATOR UNIT (FAN COIL UNIT)
5
