WhisperKool Platinum Split Quick Reference Guide

www.whisperkool.com | Page 27
Install the Filter Grille by aligning the four inside
slotted holes with the four mounting screws and slide
down. Tighten the bottom two screws through the
access holes when the grille is already in place.
WALL-MOUNT
PLATINUM SPLIT
Install the remaining four 6-32 3/8” Phillips pan
head screws in the four corners on the front of the
Evaporator Unit (Fan Coil Unit).
NOTE: The screws should be
installed with about 1/16”
between the face and screw
head.
1/16”
5
6
INSTALLING THE WALL MOUNT KIT
