FP1900B – UPPER FACE PANEL ASSEMBLY
1 A013F TACHOMETER 7000RPM
2 A015 VACUUM GAUGE
3 A014 HOUR METER
4 A0305 TEMPERATURE GAUGE
5 MP005 ROCKER SWITCH SPST
6 A094A RED INDICATOR LAMP
7 A094 GREEN INDICATOR LAMP
8 B073 20A CIRCUIT BREAKER
9 CY052 12V ELECTRIC RELAY
10 J032-3 MOMENTARY PUSH BUTTON
11 J413 IGNITION SWITCH
12 A139 TEMPERATURE CONTROL UNIT
13 A139-1 TEMPERATURE CONTROL KNOB
14 A139-2 TEMPERATURE CONTROL LABEL
15 A139-5 KNOB ROTATION LIMITER
16 A139-3 TENSION SPRING
17 A139-4 FRICTION WASHER
18 D042 #10-32 HEX NUT
19 D114 #10-32 X 5/16” SET SCREW
20 D113 #10-32 X 5/8” SET SCREW
21 D171 #4-40 X 1/4” BUTTON SCREW
22 J216 DECORATIVE TRIM LOC
23 A077-1 UPPER FACE PANEL LABEL
ITEM# / P/N / DESCRIPTION ITEM# / P/N / DESCRIPTION
6-A4
