FUEL LINE HOOK-UP KIT
9
1
5
8
6
4
2
3
7
5
TO MACHINE
TO GAS TANK
ITEM# / P/N / DESCRIPTION
1 J038 12V FUEL PUMP
2 H014 3/16” HOSE ASSY W/ 1/4” CONNECTOR
3 B089-1 1/8” FPT X 1/4” COMPRESSION
4 B029 HOSE CLAMP 1/4” - 5/8”
5 J041 Ø1/4” FUEL HOSE
FOR FORD
6 A080-3 FUEL LINE CONNECTOR
7 B031 HOSE CLAMP 1/2” - 1-1/4”
FOR CHEVY & DODGE
8 A080-2 FUEL LINE CONNECTOR
9 B094 HOSE CLAMP # 28
6-A16
