Page 11 2019
Item Description
1 M5 x 16mm long Socket-head Capscrew (T-25 Torx®)
2 Collar for M5 Capscrew
3 Hollow Pivot Pin Ø8mm x 31mm long
4 Flanged Nut M12 x 19mm long
5 Flanged Screw M12 x 15mm long
6 Rear Shock Absorber
7 Shock Extender
8 M15 x 26mm long Pivot Screw, 15mm Thread (6mm A/F Internal Hex)
9 M15 x 26mm long Pivot Screw, 15mm Thread (6mm A/F Internal Hex)
10 M6 x 20mm long Capscrew (5mm A/F Internal Hex)
11 Tapered Sleeve for Expanding Collet
12 Pivot Pin 80mm long, expanding collet, M15 thread.
13 M15 x 26mm long Pivot Screw, 10mm Thread (6mm A/F Internal Hex)
14 Chain-stays
15 Main Frame
16 Rear Suspension H Link, 99mm centre — to – centre
17 M15 x 25mm long Pivot Screw, 10mm Thread (6mm A/F Internal Hex)
18 Seat-stays
19 Shield Washer (O.D. 23mm)
20 Bearing (Enduro 6802-2RS-MAX)
21 Internal Spacer (49mm long)
22 M15 x 27mm long Pivot Screw, 14mm Thread (6mm A/F Internal Hex)
WHYTE Service Manual
